Servicing the 7x20 Controller
Slot Type Part Number Vendor Part Description Note
0 PCIe 375-3696-01 Mellanox InfiniBand HCA Optional
Recommended
Front-end
0 PCIe 375-3606-03 MHJH29-XTC InfiniBand HCA Optional
Recommended
Front-end
0 PCIe 375-3481-01 Intel
EXPI9404PT
QP Copper NIC Optional
Recommended
Front-end
0 PCIe 371-4325-01 QLogic 8Gb DP FC
HBA
Optional
FC Target
or Initiator
(Backup)
1 PCIe 375-3617-01 Intel Niantic DP Optical
10GE NIC
Optional
Recommended
Front-end
1 PCIe 375-3696-01 Mellanox InfiniBand HCA Optional
Recommended
Front-end
1 PCIe 375-3606-03 MHJH29-XTC InfiniBand HCA Optional
Recommended
Front-end
1 PCIe 375-3481-01 Intel
EXPI9404PT
QP Copper NIC Optional
Recommended
Front-end
1 PCIe 371-4325-01 QLogic 8Gb DP FC
HBA
Optional
FC Target
or Initiator
(Backup)
2 PCIe 375-3609-03 Sun Thebe External SAS
HBA
Base
Configuration
7320 Cluster Configurations
The 7320 cluster base configuration is 96GB RAM, 2x2.4GHz Quad-Core processors, one
external SAS HBA, and four 10/100/1000 Ethernet ports, and a Cluster card. The Sun Storage
7420C Cluster Upgrade Kit (XOPT 594-4680-01) contains two cluster cards with cables for
converting two 7320 or two 7420 controllers to a cluster.
The following options are available for clustered storage controllers.
Note - When you cluster a 7320, you must identically configure the cards in both of the
clustered storage controllers, and you must identically configure all optional NIC/HBA cards
used in the clustered storage controllers in both chassis.
172 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
