Servicing the 7x20 Controller
Figure Legend Figure Legend
1 Power supplies 4 Network management port
2 SC summary status LEDs 5 Ethernet ports
3 Serial management port 6 PCIe slots
7320 Electrical Specifications
The following list shows the electrical specifications for the 7320.
Note - The power dissipation numbers listed are the maximum rated power numbers for the
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Connectors
■
Two C13 connectors which work on 110-220v outlets
Input
■
Nominal frequencies: 50/60Hz
■
Nominal voltage range: 100-120/200-240 VAC
■
Maximum current AC RMS: 9.0 amps Max
■
AC operating range: 90-264 VAC
Output
■
3.3 VDC STBY: 3.6A
■
+12 VDC: 62.3A
Power Dissipation
■
Max power consumption: 873 W
■
Max heat output: 2977 BTU/hr
■
Volt-Ampere rating: 891 VA @ 240 VAC, 0.98P.F.
7320 Internal Boards
The 7320 storage controller chassis has the following boards installed.
Note - Field-replaceable units (FRUs) should only be replaced by trained Oracle service
technicians.
176 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
