Oracle DE2-24 Customer Service Manual

Servicing the Disk Shelves
FIGURE 73
Oracle Storage Drive Enclosure DE2-24C Back Panel
Figure Legend Figure Legend Figure Legend
1 Power Supply Filler Panel, Slot 0 4 Power Supply Filler Panel, Slot 3 7 I/O Module Filler Panel
2 Power Supply with Fan Module 1 5 I/O Module Filler Panel 8 I/O Module 1
3 Power Supply with Fan Module 2 6 I/O Module 0
Note - It is especially important that power supplies and their filler panels are in the correct
slots.
242 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
