How to Replace a ZS3-2 Fan Module
6.
Grasp the green band of the fan module to be removed with your forefinger and
press down on the fan module with your thumb.
7.
Pull the band straight up and lift the fan module out of the chassis.
8.
Align the replacement fan module into the fan tray slot. The green band is on the
top of the fan module and the arrow points to the rear of the chassis.
Servicing the Hardware 137
