How to Replace a ZS3-2 Memory
Removing a DIMM is a cold-service operation. You must power off the appliance before
you remove the DIMM. There will be a loss of access to the storage unless the system is in a
clustered configuration.
1.
To identify a general memory fault, go to the Maintenance > Hardware screen of
the BUI, and click on the right-arrow icon on the controller. Then click DIMMs
to locate the faulted component, indicated by the warning icon . To identify a
specific memory module that has faulted, you can open the storage controller
and use the amber status LEDs on the motherboard.
2.
Power off the storage controller as described in “How to Power off the
Controller” on page 41.
3.
Extend the controller from the rack as described in “How to Extend the Storage
Controller from the Rack” on page 41.
4.
Remove the top cover as described in “How to Remove the Top
Cover” on page 42.
5.
Disconnect the cables attached to the drive backplane, and the cable attached to
the USB board.
6.
Fully loosen the four screws securing the drive cage to the chassis (1).
Servicing the Hardware 139
