How to Replace a ZS4-4 PCIe Card
installing the HBA. All HBAs must be of the same type. Use the following procedure to replace
a ZS4-4 PCle card.
1.
Go to the Maintenance > Hardware screen of the BUI, click the right-arrow icon
for the controller, click Slot, and note the ID of the faulted PCIe card, which has
an amber icon. To highlight the location of the card in the controller picture, click
on the card ID. To view details about the faulted card, click its information icon
and then click Active Problems.
Caution - This procedure requires that you handle components that are sensitive to static
discharge, which can cause the component to fail. To avoid damage, wear an antistatic wrist
strap and use an antistatic mat when handling components.
2.
Shut down the controller using one of the power-off methods described in “How
to Power off the Controller” on page 41.
3.
Extend the controller from the rack as described in “How to Extend the Storage
Controller from the Rack” on page 41.
4.
Remove the top cover as described in “How to Remove the Top
Cover” on page 42.
5.
Locate the PCIe card position in the storage controller.
Servicing the Hardware 69
