Oshkosh M1070 - Page 43

TABLE OF CONTENTS - Continued
WP Sequence No.
Page No.
Figure 1. HET Tractor Exterior............................................ 0083-1
Figure 2. HET Tractor Exterior............................................ 0083-2
Figure 3. HET Tractor Undercarriage.................................. 0083-2
Figure 4. HET Tractor Engine Compartment
(Passenger Side)................................................................. 0083-3
Figure 5. HET Tractor Engine Compartment (Driver
Side)................................................................................. 0083-3
Figure 6. HET Tractor Forward Interior............................... 0083-4
Figure 7. HET Tractor Transmission................................... 0083-5
Figure 8. HET Tractor Rear Interior.................................... 0083-6
Chapter 3 - TROUBLESHOOTING PROCEDURES
HET TRACTOR WANDERS, PULLS TO ONE SIDE, LEANS, OR
SHIMMIES.................................................................................................... WP 0084
Figure 1. CTIS Control Panel............................................. 0084-2
Figure 2. Wheel and Wheel Cover-HET Base................... 0084-2
Figure 3. Linkage Breakdown............................................ 0084-3
Figure 4. Linkage Breakdown............................................ 0084-4
Figure 5. Linkage Breakdown............................................ 0084-5
Figure 6. Shock Absorber And Air Spring.......................... 0084-6
HET TRACTOR DIFFICULT TO STEER OR EXCESSIVE PLAY............... WP 0085
Figure 1. ............................................................................. 0085-1
Figure 2. ............................................................................. 0085-2
Figure 3. ............................................................................. 0085-3
TM 9-2320-360-10
xix
