Panasonic FP0R Series - Wiring of Analog Output Unit

3.2 Analog Output Unit (FP0R-DA4)
3-5
3.2.2 Wiring of Analog Output Unit
 When the voltage output
 When current output
(Note):All COM terminals of the voltage output terminal block and current output terminal block are connected
internally.
