Panasonic FP0R Series User Manual

4.1 I/O Allocation
4-3
Type of unit Allocation content
I/O number
Expansion
unit 1
Expansion
unit 2
Expansion
unit 3
FP0R
Analog input unit
AFP0RAD4 (Note 1)
AFP0RAD8
Input
CH0/CH2/CH4/CH6
WX2
(X20~X2F)
WX4
(X40~X4F)
WX6
(X60~X6F)
Input
CH1/CH3/CH5/CH7
WX3
(X30~X3F)
WX5
(X50~X5F)
WX7
(X70~X7F)
Output
14-bit mode range setting
WY2
(Y20~Y2F)
WY4
(Y40~Y4F)
WY6
(Y60~Y6F)
Output
14-bit mode range averaging
setting
WY3
(Y30~Y3F)
WY5
(Y50~Y5F)
WY7
(Y70~Y7F)
FP0R
Analog output unit
AFP0RDA4
Input
Status information
(Power ON/OFF, Write state)
WX2
(X20~X2F)
WX4
(X40~X4F)
WX6
(X60~X6F)
WX3
(X30~X3F)
WX5
(X50~X5F)
WX7
(X70~X7F)
Output (Note 2)
CH0/CH2
WY2
(Y20~Y2F)
WY4
(Y40~Y4F)
WY6
(Y60~Y6F)
Output (Note 2)
CH1/CH3
WY3
(Y30~Y3F)
WY5
(Y50~Y5F)
WY7
(Y70~Y7F)
FP0R
Analog I/O unit
AFP0RA21 (Note 3)
AFP0RA42
Input
CH0/CH2
WX2
(X20~X2F)
WX4
(X40~X4F)
WX6
(X60~X6F)
Input
CH1/CH3
WX3
(X30~X3F)
WX5
(X50~X5F)
WX7
(X70~X7F)
Output (Note 4)
CH0
WY2
(Y20~Y2F)
WY4
(Y40~Y4F)
WY6
(Y60~Y6F)
Output (Note 4)
CH1
WY3
(Y30~Y3F)
WY5
(Y50~Y5F)
WY7
(Y70~Y7F)
(Note 1):On AFP0RAD4, data of CH0 to CH3 is handled.
(Note 2):It can be also used for switching the output range in the 14-bit mode.
(Note 3):On AFP04A21, data of input CH0/CH1 and output CH0 is handled.
(Note 4):It can be also used for the input range, averaging setting for input and switching the output range in the 14-
bit mode.

Panasonic FP0R Series Specifications

General

Model	FP0R Series
Expansion	Up to 3 expansion units
Type	Programmable Controller
Processing Speed	0.08 µs/step
Communication Ports	RS232C, RS485
Power Supply	24 V DC
Operating Temperature	0°C to 55°C
I/O Points	Up to 128 points
CPU Type	32-bit RISC
Program Memory	Flash ROM
Dimensions	90mm x 60mm x 25mm (varies by model)
