7.1 Analog Input Unit
7-3
7.1.2 Points of Replacement
The points for replacing the conventional model FP0-A80 with the new model FP0RAD* as an
alternative are described below.
Specification
This product can be used equivalently to FP0-A80. (Note 1)
Hardware (Note 2)
The mode switch is set in the same way as FP0-A80. However, if both mode switches 1 and
2 are ON, the product operates in the 14-bit mode. (Note 1)
The supply of power (24 V DC) from an external device is not needed for the new analog
input units FP0R-AD4 and FP0R-AD8.
Software
User programs created for the conventional model FP0-A80 can be used as they are.
(Note 1): The units of Ver.1.1 or older cannot be set to the voltage range -100 to +100 mV DC.
(Note 2): In the unit of Ver.1.1 or older, a digital conversion value equivalent to the analog input of approx. 2 V is
saved in the device (WX), for the channels to which no input is connected.
REFERENCE
For details of the setting method of the mode switch, refer to “2.1.2 Setting
of Mode Switch“.
