Analog Input Averaging Processing
5.2 Setting of Averaging Processing
5.2.1 Enabling Averaging Processing
The averaging processing can be set by the following methods.
12-bit FP0-A80 compatibility mode / FP0-A21 compatibility mode
The averaging processing is enabled only when the mode switch No.5 of the unit is ON.
• The averaging method of all channels is the moving average 10 times (Max. and min.
removal).
14-bit mode
• The averaging processing is enabled only when the mode switch No.5 of the unit is ON.
• The default is the moving average 10 times (Max. and min. removal).
• It is possible to specify the averaging method (Moving average 10 times / No. of averaging
times: 64 / No. of averaging times: 128 / No averaging) by a user program for each channel.
• For details of the setting method of the mode switch, refer to the chapter 2
“Names and Functions of Parts“.
• For details of the programming method for the analog input unit (FP0R-
AD4/AD8), refer to “4.2.2 Setting of Input Range and Averaging Processing
(14-bit Mode Only)“.
• For details of the programming method for the analog I/O unit (FP0R-
A21/A42), refer to PAGEREF“4.4.5 Switching of Input Range and Averaging
Method (14-bit Mode Only)“.
