Panasonic FP7 Series User Manual

Operand Parameter Range Settings
[D+6]
RS/CS
(Note 1)
U0 to U1 U0: Disable, U1: Enable
[D+7] Send waiting time U0 to U10000
U0: Immediate Effective time = Un x 0.01 ms (0 to 100
ms)
[D+8] Header STX U0 to U1 U0: Disable, U1: Enable
[D+9] Terminator setting U0 to U3 U0: cR, U1: cR+Lf, U2: Time, U3: ETX
[D+10]
Terminator judgment
time
U0 to U10000
U0: For 32 bits
Effective time = Un × 0.01 ms (Effective only when the
terminator setting is Time)
[D+11] Modem initialization U0 to U2
U0: Not initialize
U1: Execute the first initialization only
(Note 2)
U2: Re-execute initialization at the time of setting.
[D+12] Reserved area U0 Reserved area
[D+13] Reserved area U0 Reserved area
[D+14]
Link area block
number
U0 to U1 Block number of link relay/link register area
[D+15]
PLC Link
MEWNET-W0
Max. unit No.
U2 to U16 Values outside the range are treated as 16.
[D+16] Link relay range U0 to U64
Specification of range of link relays used for
communication (Relative values in a specified block)
[D+17] Link register range U0 to U128
Specification of range of link registers used for
communication (Relative values in a specified block)
[D+18]
Starting no. for link
relay send area
U0 to U63
Starting number for link relay transmission (Specified
number of words, Relative values in a specified block)
[D+19]
Size of link relay
send area
U0 to U64
Link relay transmission size (Specified number of
words)
[D+20]
Starting No. for link
register send area
U0 to U127
Starting number for link register transmission (Specified
number of words, Relative values in a specified block)
[D+21]
Size of link register
send area
U0 to U127
Link register transmission size (Specified number of
words)
[D+22] Reserved area U0 Reserved area
[D+23] Reserved area U0 Reserved area
[D+24] Reserved area U0 Reserved area
[D+25] Reserved area U0 Reserved area
(Note 1) RS/CS is selectable only when using an RS-232C cassette (1-ch, 5-wire type).
(Note 2) The modem is initialized at the time of setting (when the power turns on, PMGET instruction is
executed, or when switching to the RUN mode). However, only the first initialization is executed
(except the time of repower-on).
(Note 3) The settings of [D+14] to [D+21] are available only when the communication mode for the COM.1 port
is PLC link.
