FPΣ User's Manual
10.2 Sampling Trace
259
10.2 Sampling Trace
Using the sampling trace function, the current contact conditions and/or the variable values
can be displayed on a time axis. After data recording in the PLC has been completed, the
data is loaded into FPWIN Pro. Sampling parameters such as the sampling time and trigger
conditions can be set in FPWIN Pro.
A maximum of 16 Boolean variables and three 16-bit variables can be traced per sampling.
REFERENCE
For details, please refer to the FPWIN Pro Programming Manual or to the FPWIN
Pro online help.
