CPU Types
FPΣ User's Manual
26
3.3 Terminal Layout
3.3.1 C32 CPU
Input connector
X0-7
COM
X5
X7
X1
X3
COM
X4
X6
X0
X2
COM
XD
XF
X9
XB
COM
XC
XE
X8
XA
X0
X1
X8-F
X8 X9
1
Connector front view
The COM terminals of the input circuits are connected internally.
Output connector
Y5
Y7
Y1
Y3
(+)
Y4
Y6
Y0
Y2
L
L
L
L
L
L
L
L
YD
YF
Y9
YB
(+)
YC
YE
Y8
YA
L
L
L
L
L
L
L
L
Y0
Y1
Y9
Y8
(–)
Y0-7 Y8-F
(–)
1
Connector front view
The (+) terminals as well as the (-) terminals of the output circuits are connected internally.
