FPΣ User's Manual
12.4 Dimensions
287
CPU with communication cassette
(100)
* With FPG-COM4: 105mm
12.4.2 Relay Output Type CPU
FPG-C24R2(H)
(10)
40
(13)
(9)(10)
FPΣ
30.0
90.0
60.0
(3.5)
60.0
90.0
Approx. 130.0
(7.5)
(5.0)
(4.5)
(2.0)
≈90
1
2
1
Maximum installation dimension
2
DIN rail (DIN EN50022 35mm)
