Communication
FPΣ User's Manual
180
• Using the 2-channel RS232C type communication cassette (FPG-COM2):
SG
S1
R1
S2
R2

1
2
3
4
5
6
7
8
9
CD
RXD
TXD
DTR
GND
DSR
RTS
CTS
RI
Left: computer, right: FPΣ
1
To second external device
• Using the 1-channel RS485 and 1-channel RS232C combination type communication
cassette (FPG-COM4):
1
2
3
4
5
6
7
8
9
CD
RXD
TXD
DTR
GND
DSR
RTS
CTS
RI
SG
+
-
SD
RD
Left: computer, right: FPΣ
8.5.5.2 1:1 Communication with Programmable Displays of GT Series
For a 1:1 MEWTOCOL-COM connection between the FPΣ and a programmable display of the
GT Series, an RS232C cable is needed. Communication is performed via commands from the
programmable display and responses from the PLC.
No program is required for communication. Simply set the mutual communication settings to
operate the PLC via the programmable display.
It is recommended to connect the computer to the TOOL port of the FPΣ. A connection cable
(order no. AFC8513D) with a 5-pin mini-DIN connector and a 9-pin Sub-D connector is
available.
