FPΣ User's Manual
12.3 I/O Allocation
285
FP0 expansion units (right side expansion)
I/O allocation is performed automatically when an expansion unit is added and is determined
by the installation location.
Unit number (installation location)
Type of unit
Number
of I/O
points
Channel
1 2 3
FP0 I/O expansion unit
FP0-E8X Input 8 – X20–X27 X40–X47 X60–X67
Input
4 – X20–X23 X40–X43 X60–X63
FP0-E8R
Output
4 – Y20–Y23 Y40–Y43 Y60–Y63
FP0-E8YR, E8YT,
E8YP
Output 8 – Y20–Y27 Y40–Y47 Y60–Y67
FP0-E16X
Input
16 – X20–X2F X40–X4F X60–X6F
Input
8 – X20–X27 X40–X47 X60–X67
FP0-E16R, E16T,
E16P
Output
8 – Y20–Y27 Y40–Y47 Y60–Y67
FP0-E16YT, E16YP
Output
16 – Y20–Y2F Y40–Y4F Y60–Y6F
Input
16 – X20–X2F X40–X4F X60–X6F
FP0-E32T, E32P
Output
16 – Y20–Y2F Y40–Y4F Y60–Y6F
Input 16 0
WX2
(X20–X2F)
WX4
(X40–X4F)
WX6
(X60–X6F)
Input 16 1
WX3
(X30–X3F)
WX5
(X50–X5F)
WX7
(X70–X7F)
FP0 analog I/O unit
FP0-A21
Output 16 –
WY2
(Y20–Y2F)
WY4
(Y40–Y4F)
WY6
(Y60–Y6F)
Input 16 0, 2, 4, 6
WX2
(X20–X2F)
WX4
(X40–X4F)
WX6
(X60–X6F)
FP0 A/D conversion unit
FP0-A80 and
FP0 thermocouple unit
FP0-TC4,
FP0-TC8
Input 16 1, 3, 5, 7
WX3
(X30–X3F)
WX5
(X50–X5F)
WX7
(X70–X7F)
Input 16 –
WX2
(X20–X2F)
WX4
(X40–X4F)
WX6
(X60–X6F)
Output 16 0, 2
WY2
(Y20–Y2F)
WY4
(Y40–Y4F)
WY6
(Y60–Y6F)
FP0 D/A conversion unit
FP0-A04V,
FP0-A04I
Output 16 1, 3
WY3
(Y30–Y3F)
WY5
(Y50–Y5F)
WY7
(Y70–Y7F)
Input 16 0, 2, 4
WX2
(X20–X2F)
WX4
(X40–X4F)
WX6
(X60–X6F)
Input 16 1, 3, 5
WX3
(X30–X3F)
WX5
(X50–X5F)
WX7
(X70–X7F)
FP0 RTD unit
FP0-RTD6
Output 16 –
WY2
(Y20–Y2F)
WY4
(Y40–Y4F)
WY6
(Y60–Y6F)
Input
32 – X20–X3F X40–X5F X60–X7F
FP0 I/O link unit
FP0-IOL
Output
32 – Y20–Y3F Y40–Y5F Y60–Y7F
NOTE
• The data for each channel of the A/D and D/A conversion units FP0-A80,
FP0-TC4/TC8, FP0-A04V/I, and FP0-RTD6 is converted and loaded with a
user program that includes a switching flag to convert the data in 16-bit
words (see corresponding manuals).
To Next Page
