1.27 Networking Features
Feature Guide 217
1.27.2 QSIG Network
1.27.2.1 QSIG Network—OVERVIEW
Description
TIE line service can be used on a private network that is established using ISDN (PRI) lines programmed
to implement the QSIG protocol (Q.931). QSIG offers TIE line service as well as advanced caller and called
party identification features.
When configuring Panasonic Hybrid IP-PBXs to establish a private network based on QSIG, the ports of
each PBX must be programmed so that each ISDN line has a "master" connection and a "slave" connection.
[Example of Private Network Established via QSIG]
The following services are available when TIE line calls are made on a private network established via
QSIG. They can be enabled or disabled for each ISDN (PRI) port.
Private Network
Slave
Master
Master
Slave
Master
Slave
Master Slave
PBX-2PBX-1
PBX-3
PBX-4
