Panasonic KX-TDA100

1.27 Networking Features
Feature Guide 225
Feature References
1.27.1 TIE Line Service
1.27.2 QSIG Network
1.27.3 Voice over Internet Protocol (VoIP) Network
Operation References
1.2.1 Basic Calling
2.1.7 Network Direct Station Selection (NDSS) Monitor Release
1.27.3 Voice over Internet Protocol (VoIP) Network
Description
The Panasonic Hybrid-IP PBX can be used on a private network which implements Voice over Internet
Protocol (VoIP).
On this type of network, information is sent over the private network in IP packets, which allows voice as
well as data to be sent to other devices in the private network.
Each PBX in the private network is connected via an IP-GW card to a local area network (LAN). A LAN can
consist of PBXs, computers, servers, routers, etc. Each LAN is connected to the private network by a router,
which is used to direct voice and data to the routers of other PBXs. These routers can be connected by
privately leased lines.
TIE line service and QSIG services can be used on a private network which implements Voice over Internet
Protocol (VoIP). (→ 1.27.1 TIE Line Service, → 1.27.2 QSIG Network)
[Example]
Conditions
• The IP address of every PBX in the private IP network must be programmed in each IP-GW.
• Some QSIG services are available. (→ 1.27.2 QSIG Network)
PBX-2
PBX-1
PBX-3
PBX-4
LAN
LAN
Router
Router
Router
Router
Private IP Network
LAN
LAN
IP-GW
IP-GW
IP-GW
IP-GW
