Digiplex EVO • Programming Guide
Version 7.11
Programmable Outputs | 25
031 Duress alarm by user
000 User codes 001 to 255 001 to 255 001 to 255
001 User codes 256 to 511 000 to 255 000 to 255
002 User codes 512 to 767 000 to 255 000 to 255
003 User codes 768 to 999 000 to 231 000 to 231
255 Any user code Not Used Not Used
032 Zone shutdown
000
255 = any zone #
Zone numbers
001 to 192 001 to 192
033 Zone tamper 001 to 192 001 to 192
034 Zone tamper restore 001 to 192 001 to 192
035 Special tamper 000
Keypad lockout 000 000
Voice lockout 001 001
036 Trouble event
000
Future use 000 000
AC failure 001 001
Battery failure 002 002
Auxiliary current limit 003 003
Bell current limit 004 004
Bell absent 005 005
Clock trouble 006 006
Global fire loop 007 007
255 Any trouble event Not Used Not Used
037 Trouble restore
000
TLM trouble 000 000
AC failure 001 001
Battery failure 002 002
Auxiliary current limit 003 003
Bell current limit 004 004
Bell absent 005 005
Clock trouble 006 006
Global fire loop 007 007
255 Any trouble restore event Not Used Not Used
038 Module trouble
000
Combus fault 000 000
Module tamper 001 001
ROM/RAM error 002 002
TLM trouble 003 003
Fail to communicate 004 004
Printer fault 005 005
AC failure 006 006
Battery failure 007 007
Auxiliary failure 008 008
001
Missing PCS module 000 000
GSM RF jam 002 002
GSM no service 003 003
Fail to communicate IPR512 1 004 004
Fail to communicate IPR512 2 005 005
Fail to communicate IPR512 3 006 006
Fail to communicate IPR512 4 007 007
Table 16: List of Event and Feature Groups (Continued)
