Parker 10G-46-0600-BF

14-6 Compliance
AC10 Inverter
Frame Size or Model
Fuse Model
Fuse Current Rating
10G-41-0006-XX
10G-41-0010-XX
10G-41-0015-XX
JJS-6
6A
10G-42-0020-XX
10G-42-0030-XX
10G-42-0040-XX
10G-42-0065-XX
JJS-15
15A
10G-43-0080-XX
10G-43-0090-XX
10G-43-0120-XX
JJS-30
30A
10G-44-0170-XX
JJS-45
45A
10G-44-0230-XX
JJS-60
60A
10G-45-0320-XX
JJS-80
80A
10G-45-0380-XX
JJS-90
90A
10G-45-0440-XX
JJS-100
100A
10G-46-0600-XX
AJT-125
125A
10G-47-0750-XX
AJT-150
150A
10G-47-0900-XX
AJT-200
200A
10G-48-1100-XX
AJT-200
200A
10G-48-1500-XX
AJT-300
300A
10G-49-1800-XX
AJT-350
350A
10G-49-2200-XX
AJT-400
400A
10G-410-2650-XX
AJT-500
500A
10G-411-3200-XX
AJT-600
600A
10G-411-3600-XX
AJT-600
600A
g) “Integral solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the National Electrical
Code and any additional local codes” or equivalent.
h) “CAUTION – Risk of Electric Shock” should be provided, followed by instructions to
discharge the Bus Capacitor or indicating the time required (5 minutes) for Bus
Capacitor to discharge to a level below 50Vdc.
i) “Drives have no provision for motor over temperature protection” or equivalent.
j) For use in Canada only: “TRANSIENT SURGE SUPPRESSION SHALL BE
INSTALLED ON THE LINE SIDE OF THIS EQUIPMENT AND SHALL BE RATED
____480/240 ___V (PHASE TO GROUND), 480/240V (PHASE TO PHASE),
SUITABLE FOR OVERVOLTAGE CATEGORY _III___, AND SHALL PROVIDE
PROTECTION FOR A RATED IMPULSE WITHSTAND VOLTAGE PEAK OF _ 6Kv”
or equivalent.
k) Field wiring terminal markings – Wiring terminals shall be marked to indicate the
proper connections for power supply and load, or a wiring diagram coded to the
terminal marking shall be securely attached to the device.
l) “Use 60/75
o
C CU wire” or equivalent.
