6-2 The Menu
AC10 Inverter
6.1.1 Function Codes Switchover in/between Code-Groups
It has more than 300 parameters (function codes) available to the user, divided into sections
as indicated in Table 6-3.
Table 6-3 Function Code Partition
Timing control
and protection
function
Multi-functional
input/output terminal
Analog signals and
pulse of input/output
Multi-stage speed
Parameters
As parameter setting can take time due to numerous function codes, such function is specially
designed as “Function Code Switchover in a Code Group or between Two Code-Groups” so
that parameters setting becomes convenient and simple.
Press “M” key so that the keypad controller will display function code. If user presses “▲” or
“▼” key, the function code will circularly keep increasing or decreasing by degrees within the
group; if user presses the “O” key again, the function code will change circularly between two
code groups when operating the “▲” or “▼” key, e.g. when function code shows F111 and
DGT indicator is on, press “▲”/ “▼” key, function code will keep increasing or decreasing by
degrees within F100～F160; press “O” key again, DGT indicator will be off. When pressing
“▲”/ “▼” key, function codes will change circularly among the 10 code-groups, like F211,
F311…FA11, F111…, Refer to Figure 6-1 (The flashing “ is indicated the corresponding
target frequency values).
(The flashing “ is indicated the corresponding target frequency values).
Figure 6-1 Switch over in a Code Group or between Different Code-Groups
Enter correct user’s password
(currently showing 50.00)
