Parker 10G-46-0600-BF

Parameter Reference 15-17
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F903
Parity Check
0: None
1: Odd
2: Even
0
√
F904
Baud Rate
0: 1200
1: 2400
2: 4800
3: 9600
4: 19200
5: 38400
6: 57600
3
√
F905
Communication Timeout
0.0~3000.0
0.0
√
F906-
F930
Reserved
PID parameters: FA00-FA80
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
FA01
PID reference signal source
0: FA04
1: AI1
2: AI2
0
╳
FA02
PID feedback signal source
1: AI1
2: AI2
0
√
FA03
Max limit of PID adjusting (%)
FA04～100.0
10.0
√
FA04
Digital setting value of PID adjusting (%)
FA05～FA03
50.0
√
FA05
Min limit of PID adjusting (%)
0.0～FA04
0.0
√
FA06
PID polarity
0: Positive feedback
1: Negative feedback
1
╳
FA07
Sleep function selection
0: Valid
1: Invalid
0
╳
FA09
Min frequency of PID adjusting (Hz)
Max(F112, 0.1)~F111
5.00
√
FA10
Sleep delay time (s)
0~500.0
15.0
√
FA11
Wake delay time (s)
0.0~3000
3.0
√
FA12
Maximum output frequency of PID loop
FA09 – F111
50.00
√
FA18
Whether PID target is changed
0: Disabled
1: Enabled
1
╳
FA19
Proportion Gain P
0.00~10.00
0.3
√
FA20
Integration time I (s)
0.0~100.0S
0.3
√
FA21
Differential time D (s)
0.00~10.00
0.0
√
FA22
PID sampling period (s)
0.1～10.0s
0.1
√
FA29
PID dead time (%)
0.0～10.0
2.0
√
FA58
Fire pressure given value (%)
0.0~100.0
80.0
√
