Parker 10G-46-0600-BF

15-16 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F809
Mutual Inductance(mH)
0.01～655.3mH (22kW and below)
0.001~65.53mH (above 22kW)
Subject to
inverter
model
○╳
F810
Motor Rated Frequency
1.00~590Hz
50.00
○╳
F812
Pre-exciting Time
0.000～30.00S
0.30
√
F813
Rotary Speed Loop KP1
0.01～20.00 (22kW and below)
1~100 (above 22kW)
Subject to
inverter
model
○√
F814
Rotary Speed Loop KI1
0.01～2.00 (22kW and below)
0.01~10.00 (above 22kW)
Subject to
inverter
model
○√
F815
Rotary Speed Loop KP2
0.01～20.00 (22kW and below)
1~100 (above 22kW)
Subject to
inverter
model
○√
F816
Rotary Speed Loop KI2
0.01～2.00 (22kW and below)
0.01~10.00 (above 22kW)
Subject to
inverter
model
○√
F817
PID Switching Frequency 1
0~F111
5.00
√
F818
PID Switching Frequency 2
F817~F111
50.00
√
F819~
F860
Reserved
Subject to
inverter
model
√
F870
PMSM back electromotive force (mV/rpm)
0.1～999.9
Subject to
inverter
model
○
F871
PMSM D-axis inductance (mH)
0.01～655.35
Subject to
inverter
model
○
F872
PMSM Q-axis inductance (mH)
0.01～655.35
Subject to
inverter
model
○
F873
PMSM stator resistance（Ω）
0.001～65.535
Subject to
inverter
model
○
F876
PMSM injection current without load (%)
0.0～100.0
20.0
×
F877
PMSM injection current compensation
without load (%)
0.0～50.0
0.0
×
F878
PMSM cut-off point of injection current
compensation without load (%)
0.0～50.0
10.0
×
Communication parameter: F900-F930
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F900
Communication Address
1~255: single inverter address
0: broadcast address
1
√
F901
Communication Mode
1: ASCII
2: RTU
1
○√
F902
Stop Bits
1～2
2
√
