Compliance 14-5
AC10 Inverter
14.4 North American & Canadian Compliance Information (Frame 1 – 5 ONLY)
14.4.1 UL Standards
The UL/cUL mark applies to products in the United States and Canada and it means that UL
has performed product testing and evaluation and determined that their stringent standards
for product safety have been met. For a product to receive UL certification, all components
inside that product must also receive UL certification:
14.4.2 UL Standards Compliance
This drive is tested in accordance with UL standard UL508C, File No. E142140 and complies
with UL requirements. To ensure continued compliance when using this drive in combination
with other equipment, meet the following conditions:
1. Do not install the drive to an area greater than pollution severity 2 (UL standard).
2. Installation and operating instructions shall be provided with each device.
The following markings shall appear in one of the following locations; shipped separately
with the device; on a separable, self-adhesive permanent label that is shipped with the
device; or anywhere on the device itself.
a) Designation markings for each wiring diagram.
b) Markings for proper wiring connections.
c) “Maximum surrounding air temperature 40
o
C” or equivalent.
d) “Solid state motor overload protection reacts when reaches 150% of FLA” or
equivalent.
e) “Install device in pollution degree 2 environment.” Or equivalent.
f) “Suitable for use on a circuit capable of delivering not more than 5,000 rms
symmetrical amperes, 480/240 volts maximum when protected by made by COOPER
BUSSMANN LLC Class T Fuse.” Or equivalent. Recommended input fuse selection
listed below:
10G-31-0025-XX
10G-31-0035-XX
10G-31-0045-XX
10G-32-0050-XX
10G-32-0070-XX
10G-32-0100-XX
10G-11-0025-XX
10G-11-0035-XX
10G-11-0045-XX
10G-12-0070-XX
10G-12-0010-XX
