9.3.3 Analog input monitoring
The value of analog is displayed by 0~4095.
F335
Relay output simulation
Setting range:
0：Output true
1：Output false
Mfr’s value: 0
F336
DO1 output simulation
Mfr’s value: 0
F337
DO2 output simulation
Mfr’s value: 0
As an example of DO1 output simulation, when inverter is in the stop status and enter F336,
press the UP key, the DO1 terminal is valid. Release the UP key, DO1 remains valid status.
After quitting F336, DO1 will revert to initial output status.
F338
AO1 output simulation
Setting range: 0～4095
Mfr’s value: 0
F339
AO2 output simulation
When inverter is in the stop status, and enter F338, press the UP key, the output analog will
increase, and when press the DOWN key, the output analog will decrease. After quitting the
parameters, AO1 will revert to initial output status.
F340 Selection of
terminal negative logic
Setting range:
0: None
1: DI1 negative logic
2: DI2 negative logic
4: DI3 negative logic
8: DI4 negative logic
16: DI5 negative logic
32: DI6 negative logic
64: DI6 negative logic
128: DI8 negative logic
Mfr’s value: 0
For example if user wants to set DI1 and DI4 to negative logic, set F340=1+8=9
9.4 Analog Input and Output
AC10 series inverters have 2 analog input channels and 2 analog output channels.
F400 Lower limit of AI1 channel input (V)
Setting range: 0.00～F402
Mfr’s value: 0.04
F401 Corresponding setting for lower limit
of AI1 input
Setting range: 0～F403
Mfr’s value: 1.00
F402 Upper limit of AI1 channel input (V)
Setting range: F400～10.00
Mfr’s value: 10.00
F403 Corresponding setting for upper limit
of AI1 input
Setting range:
Max (1.00，F401) ～2.00
Mfr’s value: 2.00
F404 AI1 channel proportional gain K1
Setting range: 0.0～10.0
Mfr’s value: 1.0
F405 AI1 filtering time constant (s)
Setting range: 0.1～10.0
Mfr’s value: 0.10
When using analog inputs for speed control, sometimes it is necessary to scale the
relationship between the upper limit and lower limit of the value input analog, analog changes
and the output frequency, to achieve a satisfactory speed control effect.
The upper and lower limit of analog input are set by F400 and F402.
F331Monitoring AI1
Only read
F332 Monitoring AI2
Only read
