Parker 10G-46-0600-BF

9-10 Function Parameters
AC10 Inverter
9.2 Operation Control
F200
Source of start command
Setting range:
0: Keypad command;
1: Terminal command;
2: Keypad＋Terminal;
3: MODBUS;
4: Keypad＋Terminal＋MODBUS
Mfr’s
value: 4
F201
Source of stop command
Setting range:
0: Keypad command;
1: Terminal command;
2: Keypad＋Terminal;
3: MODBUS;
4: Keypad＋Terminal＋MODBUS
Mfr’s
value: 4
F200 and F201 are the resource of selecting inverter control commands.
Inverter control commands include: starting, stopping, forward running, reverse running,
jogging, etc.
”Keypad command” refers to the start/stop commands given by the “I” or “O” key on the
keypad.
“Terminal command” refers to the start/stop command given by the “I” terminal defined by
F316-F323.
When F200=3 and F201=3, the running command is given by MODBUS communication.
When F200=2 and F201=2, “keypad command” and “terminal command” are valid at the mean
time, F200=4 and F201=4 are the same.
F202
Mode of direction setting
Setting range:
0: Forward running locking;
1: Reverse running locking;
2: Terminal setting
3: Keypad
Mfr’s
value: 0
The running direction is controlled by this function code together with other speed control
mode which can set the running direction of inverter. When auto-circulation speed is selected
by F500=2, this function code is not valid.
When speed control mode without controlling direction is selected, the running direction of
inverter is controlled by this function code, for example, keypad controls speed.
F203
Main frequency source X
Setting range:
0: Memory of digital given;(adjust with keypad)
1: External analog AI1;
2: External analog AI2;
3: Reserved;
4: Stage speed control;
5: No memory of digital given;
6: Reserved;
7: Reserved;
8: Reserved;
9: PID adjusting;
10: MODBUS
Mfr’s value: 0
Main frequency source is set by this function code.
0: Memory of digital given
Its initial value is the value of F113. The frequency can be adjusted through the keypad “up” or
Direction given by F202
Direction given by
other control mode
Running direction
Remarks
0
0
0
0 means forward.
1 means reverse.
0
1
1
1
0
1
1
1
0
