9-48 Function Parameters
AC10 Inverter
FC22
Forward speed limited channel
0: Digital given (FC23)
(adjust with keypad)
1: Analog input AI1
2: Analog input AI2
0
FC23
Forward speed limited (%)
0～100.0
10.0
FC24
Reverse speed limited channel
0: Digital given (FC25)
(adjust with keypad)
1: Analog input AI1
2: Analog input AI2
0
FC25
Reverse speed limited (%)
0～100.0
10.00
Speed limited FC23/FC25: if given speed reaches max value, they are used to set percent of
inverter output frequency and max frequency F111.
FC28
Driving torque limit reference
source
0: Digital given (FC30)
(adjust with keypad)
1: Analog input AI1
2: Analog input AI2
0
FC29
Driving torque limit coefficient
0～3.000
3.000
FC30
Driving torque limit (%)
0～300.0
200.0
FC31
Re-generating torque limit channel
0: Digital given (FC35)
(adjust with keypad)
1: Analog input AI1
2: Analog input AI2
0
FC34
Re-generating torque limit
coefficient
0～3.000
3.000
FC35
Re-generating torque limit (%)
0～300.0
200.00
When motor is in the driving status, output torque limit channel is set by FC28, and limit torque
is set by FC29.
When motor is in the re-generating status, re-generating torque limit channel is set by FC31,
and limit torque is set by FC34.
