Quantum GX2 microCT Imaging System Manual Chapter 3 | Quantum GX2 microCT Imaging System Components 17

Figure 3.4 Quantum GX2 microCT Imaging System Front Panel

Figure 3.5 Quantum GX2 microCT Imaging System Sample Chamber

Emergency OFF button

Power ON/OFF button

Y-axis stage controls

X-axis stage controls Z-axis stage controls

Bore cover

Sample bed

Sample table
