Quantum GX2 microCT Imaging System Manual Chapter 5 | Working With Databases and Data 31
5.3 Data Organization
The image data (series) in a database are associated with a study and a sample (Figure 5.4). A sample
may include multiple studies and a study may include one or more series.
Customizing the Database View
You can select particular columns and data to display in the Database window.
To hide/show columns:
1.
Right-click a column header in the Database window (Figure 5.5).
2. Select Configure Display Columns on the shortcut menu that appears.
3. In the dialog box that appears, remove or add a check mark next to a column name that you want
hide or show. Click OK.
Figure 5.4 Database Window
Series (image data)
Samples
A sample includes one or
more studies. This example
shows one sample which
has two studies.
Studies
A study includes one or
more "series" of image data.
