Quantum GX2 microCT Imaging System Manual Chapter 6 | Image Acquisition 45
Custom Scan Conditions
There are two ways to set custom scan conditions:
 Edit the scan parameters in the Control Panel (see below). These changes will not be saved to the
system.
or
 Create and save a scan condition in the Menu Settings table (see page 46). The custom scan
condition will be available in the Menu drop-down list of the Control Panel
To edit scan parameters in the Control Panel:
1.
Select "Manual" from the Menu drop-down list.
2. Enter a custom voltage and current in the Control Panel (Figure 6.6).
3. Select FOV and Scan Mode. See Table 3.2 on page 19 for more details on these parameters.
20 FOV36
High Resolution, 14min
90 88 40 36 36 High
Resolution
14 min Off
21 FOV25
High Speed, 8sec
90 88 40 36 25 High Speed 08 sec Soft
22 FOV25
Standard, 18sec
90 88 40 36 25 Standard 18 sec Soft
23 FOV25
Standard, 2min
90 88 40 36 25 Standard 02 min Soft
24 FOV25
High Resolution, 4min
90 88 40 36 25 High
Resolution
04 min Off
25 FOV25
High Resolution, 14min
90 88 40 36 25 High
Resolution
14 min Off
26 FOV72
High speed, whole body
90 88 40 72 72 High Speed Whole
Body
8 sec x 3
Off
27 FOV 60
High speed, whole body
90 88 40 72 60 High Speed Whole
Body
8 sec x 3
Off
Table 6.2 Preset Scan Configurations (continued)
See Table 3.2 on page 19 for a description of the scan parameters.
Note: FOV 45, 60 and 72 can be used with the small or large bore. FOV 25 and 36 can only be used with the small bore.
No.
Menu Name
kV CT
µA
Live µA Acquisition
FOV (mm)
Recon
FOV (mm)
Scan Mode Scan
Time
Display
Settings
