6 Image Acquisition
Imaging System Warm-Up
Select a Save Location on page 41
Set Up Automatic Image Export on page 43
Set the Scan Conditions on page 43
Place a Subject in the Sample Chamber on page 47
CT Scan Without Gating on page 51
CT Scan With Respiratory Gating on page 52
CT Scan With Cardiac Gating on page 55
Reconstructing a Subvolume or Slice on page 58
Acquisition in Fluoroscopy Mode on page 62
Ring Reduction on page 63
Imaging With Different X-Ray Filters on page 64
6.1 Imaging System Warm-Up
Check the Control Panel to see if the imaging system requires warm-up (Figure 6.1). If the Control
Panel is not open, click the
icon on the desktop.
NOTE: If the imaging system is not turned on, see Starting the Imaging System on page 26 for
instructions.
Figure 6.1 Control Panel
Warm-Up Required
X-rays are OFF
Click to begin
warm-up
Warm-Up in Progress
X-rays are ON
Live Mode button
appears after
Warm-Up Complete
X-rays are OFF
Ready for acquisition
