Perle IOLAN SDS - I;O; Top View; End View of IOLAN I;O

Hardware and Connectivity 37
Getting to Know Your IOLAN
I/O
This sections describes the basic components found on the IOLAN I/O models.
Top View
The following image shows a typical IOLAN I/O model. Your I/O model may have I/O connectors in
slightly different positions.
End View of IOLAN I/O
The IOLAN I/O model shown is an A4D2. Different IOLAN I/O models have different I/O connector
configurations.
Serial Activity
Activity (LAN)
Link/10/100
Power/Ready
External Power Supply
Serial Port
Ethernet
Reset
Console/Serial
Switch
External Power Supply
I/O connectors
I/O connectors
