Getting to Know Your IOLAN
1-port, 2-port and 4-Port Wireless desktop models
This sections describes the components found on the IOLAN wireless models.
Top View (1 or 2 Port)
The following image shows an IOLAN one or two port wireless model.
Ethernet
Link/10/100/100
WLAN
External Power Supply Connection
Antenna
Power/Ready
Soft-AP Mode
Serial Ports
WPS Mode
Signal Strength
Power Terminal Plug
Reset ButtonWPS Button
Console/Serial
Switch
Grounding Screw
Ethernet Link
Serial Ports
10/100/1000
Power Terminal Plug
Antenna
External Power
Supply connection
Reset Switch
Grounding Screw
Console/Serial Switch
