Perle IOLAN SDS - 1-Port, 2-Port and 4-Port LTE Desktop Models; Top View; End Views of IOLAN LTE

Hardware and Connectivity 40
Getting to Know Your IOLAN
1-port, 2-port and 4-Port LTE desktop models
Top View
The following image shows an IOLAN LTE model.
End Views of IOLAN LTE
The 4-port IOLAN SDS L has either 1, 2 or 4 port RJ-45 serial connections.
Ethernet
Link/10/100/1000
Power/Ready
Console/Serial
External Power Supply
Connector
Antennas
Reset
Switch
Button
Serial Ports
WWAN
External Terminal Plug
Grounding Screw
SIM card slot
Signal
Strength
Antennas Serial Ports
Ethernet Link
10/100/1000
Power Terminal plug
External Power Supply
Connections
Console/Serial
Switch
Grounding
Screw
