Hardware and Connectivity 39
Getting to Know Your IOLAN
Top View (4 port RJ-45)
The following image shows an IOLAN WLAN model.
End Views of IOLAN Wireless
The 4-port IOLAN wireless has four RJ-45 serial connections. The 1-port and 2-port wireless IOLAN
have either one or two DB9M connectors depending on the model.
Ethernet
Link/10/100/1000
Console/Serial Switch
Grounding Screw
WPS
Power Terminal PlugReset
Serial Ports
Power/Ready
WLAN
Signal Strength
Antennas
Antennas Serial Ports
Power Terminal Plug
Console/Serial Switch
Grounding Screw
External Power Connection
Reset Switch
Ethernet
Link/10/100/1000
