13 - 67
Adjustment
4 472 Hook knife I
I = yes
II = no
5 585 Speed limiter N1 1200
591 Speed limiter
I = yes
II = no I
6 605 Speed display
I = yes
II = no I I
607 Max. speed 100 - 10000 3200
(-1/34 and -1/44)
4000
(-1/32 and -1/42)
617 Inverted bartacks
I = yes II
II = no
665 Pedal lock
I = contact closed I
II = contact open
679 Pedal lock off by cancelling input
signal II
680 Interruption of operation II
7 700 Needle position 0
Needle reference position 0 - 239
702 -1/32 and -1/42:
Needle position 1 (needle lowered) 0 - 239
-1/34 and –1/44
1
st
stop position, when the needle
point is positioned 1-2 mm below the
top edge of the needle plate
703 Needle position 2 (take-up lever raised) 0 - 239
799 Machine class lockstitch 2
13.09 Parameter setting
Group Parameter Description Adjustment rangeStandardvalue
For more information see the motor instruction manual.
