10 - 4
Sewing
10.02.03 Programmed sewing (program numbers 2 – 200)
Using the program numbers 2 – 200, seam programs programmed beforehand can be
selected.
● Select SEWING
mode.
● Select program selection
function.
● Enter desired program number from
2 - 2002 - 200
2 - 2002 - 200
2 - 200.
● Confirm input with Enter.
0
0
2
to
Enter
2
● The programmed amounts of fullness (seam areas) are processed consecutively
dependent on the programmed number of stitches.
In seam areas, which were programmed without details of the number of stitches
(number of stitches = 0), switch to the next area using the right knee switch.
Displays in the status bar:
Program number
The number of the selected seam program appears next to this symbol.
Seam areas left/right
The number of the seam areas for left and right parts is shown next to this symbol.
Set length
The set length of the current seam section is shown next to this symbol. If no value is given,
with the use of the knee switch the program moves on to the next seam section.
Text displays:
Beginning of seam
Seam area sewn
Current seam area Current seam area
Current seam area Current seam area
Current seam area (with seam area number)
End of seam
Display presentation is not true to scale.
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
bdf
2 4 | 5
4
