9 - 2
Setting up
9.02 Winding the bobbin thread, adjusting the thread tension
● Place the empty bobbin 1 onto the bobbin winder spindle 2.
● Thread the thread in accordance with Fig. 09-02 and wind it a few times around bobbin
1 in a clockwise direction.
● Switch the bobbin winder on by pushing the bobbin winder spindle 2 and lever 3
simultaneously.
The bobbin is wound during sewing.
● The tension of the thread on bobbin 1 can be adjusted using milled screw 4.
● The bobbin winder stops automatically when bobbin 1 is full.
If the thread is wound irregularly:
● Loosen nut 5.
● Turn thread guide 6 accordingly.
● Tighten nut 5.
Fig. 09 - 02
2
3
1
5
6
4
