9 - 1
Setting up
49-048
Fig. 9 - 01
9 Setting up
All instructions and regulations in this instruction manual must be observed.
Special attention must be given to all safety regulations!
All setting-up work must only be done by personnel with the necessary
training. For all setting-up work the machine must be isolated from its power
supply by turning off the main switch or removing the machine plug from the
electric power socket!
9.01 Inserting the needle
Switch off the machine!
Danger of injury if the machine
is started accidentally!
Raise the needle bar to its highest
position.
Loosen screw 1.
Insert the needle 2 in the needle bar as
far as it will go.
(The long needle groove must be
pointing left – as seen in the direction of
sewing.)
Tighten screw 1.
Only use 134 KK system
needles.
1
2
