Item Function Name of the picto-
gram in the operat-
ing instructions
1 Leak rate digital display -
2
1)
Display 2
nd
digit
-
3
1)
COR indicator: correction factor applied COR
4
1)
Zero indicator: zero function applied ZERO
5 Leak rate unit -
6 Test mode selected -
7 Current status of the detector -
8
2)
Stop the recording [STOP REC]
9
2)
Start recording [START REC]
10
2)
Total recording time
● white dot: no recordings in progress
● flashing red dot: recording in progress
● fixed red dot: recording paused
-
11
2)
Pause/Resume recording [STBY REC]
12
2)
Comments access [COMMENT]
13 Bar graph display of the leak rate
● Green bargraph: measured leak rate below the warning point
● Orange bargraph: measured leak rate between the warning point
and the reject point
● Red bargraph: measured leak rate above the reject point
-
14 Access to the menu Settings [SETTINGS]
15 Function key bar -
16 Set reject point (red plot) -
17
1)
Warning point set (orange plot) -
18 Display/Hide an area [EXPAND]
19 Display time -
20
3)
Leak rate plot
● 20a - white plot: measured leak rate below the warning point
● 20b - orange bargraph: measured leak rate between the warning
point and the reject point
● 20c - red plot: measured leak rate above the reject point
-
21 Detector inlet pressure plot (blue) -
22 Detector inlet pressure range -
23 Data on recording
● Tracer gas selected
● Sampling rate set
-
24 Show/hide data on recording (item 23) -
25 Detector inlet pressure unit -
1) Display according to detector settings
2) Display according to recording settings
3) Display if test in progress
Navigation
The user can view some or all of a recording, without stopping the recording in progress.
►
Drag the plot to the left/right to browse the recording in progress.
►
Press on the graph screen then [View record] to view all of the recording in progress.
Operation
