Spare Parts List
EN 168 BJ3.0E PA10.
5S05 4822 157 11411 Bead 80Ω at 100MHz
5S08 4822 526 10704 Bead 50 Ω at 100MHz
5S09 4822 157 11411 Bead 80Ω at 100MHz
5S10 2422 549 43769 Bead 30Ω at 100MHz
5S11 4822 157 11411 Bead 80Ω at 100MHz
5S12 4822 526 10704 Bead 50 Ω at 100MHz
5S14 2422 549 44197 Bead 220Ω at 100MHz
5S15 2422 549 44197 Bead 220Ω at 100MHz
5S16 4822 157 11716 Bead 30Ω at 100MHz
d
6P01 9322 203 12673 BYV27-600
6P02 9322 203 12673 BYV27-600
6P03 9322 208 83685 BZG05C27
6P04 9322 208 83685 BZG05C27
6P05 9322 233 91687 Bridge GBL08L-7000E3
6P06 9322 099 61685 BYG10J
6P09 4822 130 11522 UDZ15B
6P10 9322 202 75687 BYW29FP-200
6P11 9322 202 75687 BYW29FP-200
6P12 9322 202 75687 BYW29FP-200
6P13 9322 202 75687 BYW29FP-200
6P22 4822 130 11522 UDZ15B
6P23 4822 130 11522 UDZ15B
6P27 9322 202 55685 BYG22D
6P28 4822 130 11397 BAS316
6P31 4822 130 11522 UDZ15B
6P47 9322 208 44685 BZG05C6V8
6P50 4822 130 11522 UDZ15B
6P51 4822 130 11416 PDZ6.8B
6P53 4822 130 11397 BAS316
6P80 4822 130 11397 BAS316
6P81 4822 130 11152 UDZ18B
6P82 4822 130 11397 BAS316
6P83 4822 130 11397 BAS316
6P84 4822 130 11397 BAS316
6P85 4822 130 11397 BAS316
6P86 4822 130 11397 BAS316
6S01 5322 130 31938 BYV27-200
6S04 9340 548 69115 PDZ27B
6S05 4822 130 11522 UDZ15B
6S07 4822 130 11572 STPS8H100F
6S09 4822 130 11522 UDZ15B
6S10 9322 102 64685 UDZ2.7B
6S11 4822 130 11397 BAS316
6S12 9322 202 55685 BYG22D
6S13 4822 130 11397 BAS316
6S30 9322 203 12673 BYV27-600
6S31 4822 130 11522 UDZ15B
6S47 9322 208 44685 BZG05C6V8
6S49 3198 020 55680 BZX384-C5V6
ce
7P02 9322 194 26687 STP6NK60Z
7P03 9322 192 16685 TS2431AI
7P09 3198 010 42310 BC847BW
7P10 3198 010 42310 BC847BW
7P11
h 9322 149 04682 TCET1102
7P12
h 9322 149 04682 TCET1102
7P14 9340 557 69127 PHX9NQ20T
7P15 3198 010 42310 BC847BW
7P16 9322 192 16685 TS2431AI
7P20 9340 436 50115 BSP030
7P21 3198 010 42310 BC847BW
7P22 3198 010 42320 BC857BW
7P23 9340 436 50115 BSP030
7P24 3198 010 42320 BC857BW
7P26 9340 219 30115 BC817-25W
7P27 9352 743 34518 TEA1506AT/N1
7P80 3198 010 42310 BC847BW
7P81 9322 192 16685 TS2431AI
7P82 3198 010 42320 BC857BW
7S02 9322 194 26687 STP6NK60Z
7S03
h 9322 149 04682 TCET1102
7S04 9322 192 16685 TS2431AI
7S10 9352 700 18518 ITEA1533AT/N1
7S11 9340 219 30115 BC817-25W
7S31 9340 436 50115 BSP030
7S40 3198 010 42310 BC847BW
Small Signal Board [B]
e Software (see www.p4c.philips.com)
0802 3104 337 01901 See Philips Website
Various
1B01 2422 033 00018 Connector 19p f
1B02 2422 033 00018 Connector 19p f
1C33 2422 086 11092 Fuse 500mA 50V F SMD
1C51 2422 549 44369 SAW 38.9MHz K9656L
1C52 2422 549 44372 SAW 38.9MHz K3953L
1E40 2422 025 17601 Connector 40p f
1E62 2422 025 17759 Connector 20p f
1G01 2422 540 00017 Reson. 60MHz CSTCW
1G02 2422 540 00012 Reson. 10MHz CSTCE
1G50 2422 025 18427 Connector 31p f
1H00 2422 543 01397 Xtal 27MHz 18pF
1H01 2422 025 17775 Socket USB 4p f
1LA0 2422 543 01443 Xtal 16MHz 20pF
1M03 2422 025 10771 Connector 10p m
1M15 2422 025 18749 Connector 3p m
1M46 2422 025 10655 Connector 11p m
1M52 2422 025 18744 Connector 9p m
1M59 2422 025 19265 Connector 5p m Bk
1M64 2422 025 18779 Connector 4p m
1N00 2422 543 01095 Res. 12MHz DSX840
1N62 2422 025 18779 Connector 4p m
1P01 2422 025 19501 Socket PCMCIA H 68P f
1T05 3112 297 14651 Tuner TD1316AF/IHP-3
1U01
h 2422 086 00623 Fuse 3A T 125V
1U04
h 2422 086 00623 Fuse 3A T 125V
g
2A01 2238 586 59812 100nF 20% 50V 0603
2A20 4822 124 12095 100µF 20% 16V
2A21 4822 124 12095 100µF 20% 16V
2A22 2022 552 05679 1µF 10% 16V 0805
2A23 2020 552 96618 1nF 10% 50V 0402
2A24 2238 586 59812 100nF 20% 50V 0603
2A29 2238 586 59812 100nF 20% 50V 0603
2A31 2238 586 59812 100nF 20% 50V 0603
2A32 4822 124 80151 47µF 16V
2A34 2238 869 15101 100pF 5% 50V 0402
2A35 2238 869 15101 100pF 5% 50V 0402
2A36 2238 869 15101 100pF 5% 50V 0402
2A37 2020 552 96628 10nF 10% 16V 0402
2A38 2238 869 15101 100pF 5% 50V 0402
2A39 2020 552 96618 1nF 10% 50V 0402
2A79 2022 552 05679 1µF 10% 16V 0805
2A81 2022 552 05679 1µF 10% 16V 0805
2A83 2022 552 05679 1µF 10% 16V 0805
2A84 2022 552 05679 1µF 10% 16V 0805
2A85 2238 586 59812 100nF 20% 50V 0603
2A86 2022 552 05679 1µF 10% 16V 0805
2A87 2022 552 05679 1µF 10% 16V 0805
2A88 2238 586 59812 100nF 20% 50V 0603
2A91 2022 552 05679 1µF 10% 16V 0805
2A93 2238 586 59812 100nF 20% 50V 0603
2A96 2238 586 59812 100nF 20% 50V 0603
2A98 4822 126 14324 33pF 5% 50V 0402
2A99 4822 126 14324 33pF 5% 50V 0402
2AA0 4822 124 12095 100µF 20% 16V
2AA1 4822 124 80151 47µF 16V
2AA2 4822 124 12095 100µF 20% 16V
2AA3 2238 586 59812 100nF 20% 50V 0603
2AA4 4822 124 12108 100µF 20% 4V
2AB1 2020 552 96618 1nF 10% 50V 0402
2AB2 2020 552 96618 1nF 10% 50V 0402
2AB5 2020 552 96618 1nF 10% 50V 0402
2B00 2238 586 59812 100nF 20% 50V 0603
2B01 2238 586 59812 100nF 20% 50V 0603
2B04 2238 586 59812 100nF 20% 50V 0603
2B05 2238 586 59812 100nF 20% 50V 0603
2B22 2020 552 96628 10nF 10% 16V 0402
2B23 2020 552 96628 10nF 10% 16V 0402
2B24 2020 552 96628 10nF 10% 16V 0402
2B25 2020 552 96628 10nF 10% 16V 0402
2B26 2020 552 96628 10nF 10% 16V 0402
2B27 2020 552 96628 10nF 10% 16V 0402
2B28 2020 552 96628 10nF 10% 16V 0402
2B29 2020 552 96628 10nF 10% 16V 0402
2B30 2020 552 96628 10nF 10% 16V 0402
2B31 2020 552 96628 10nF 10% 16V 0402
2B33 2238 869 15109 10pF 5% 50V 0402
2B35 2238 869 15109 10pF 5% 50V 0402
2B37 2238 869 15109 10pF 5% 50V 0402
2B38 2022 552 05679 1µF 10% 16V 0805
2B39 2020 004 00003 330µF 20% 6.3V
2B40 2238 586 59812 100nF 20% 50V 0603
2B41 2238 586 59812 100nF 20% 50V 0603
2B42 2238 586 59812 100nF 20% 50V 0603
2B44 2020 552 96628 10nF 10% 16V 0402
2B45 2020 552 96628 10nF 10% 16V 0402
2B46 2020 552 96628 10nF 10% 16V 0402
2B49 2238 586 59812 100nF 20% 50V 0603
2B51 2238 586 59812 100nF 20% 50V 0603
2B52 2238 586 59812 100nF 20% 50V 0603
2B53 2238 586 59812 100nF 20% 50V 0603
2B62 2238 586 59812 100nF 20% 50V 0603
2B64 2238 586 59812 100nF 20% 50V 0603
2B67 4822 124 81058 47µF 20% 4V
2B69 2238 586 59812 100nF 20% 50V 0603
2B77 2238 586 59812 100nF 20% 50V 0603
2B79 2238 586 59812 100nF 20% 50V 0603
2B80 2238 586 59812 100nF 20% 50V 0603
2B81 2238 586 59812 100nF 20% 50V 0603
2B89 5322 126 11583 10nF 10% 50V 0603
2B90 4822 124 81058 47µF 20% 4V
2B92 2238 787 15641 22nF 5% 16V 0402
2BA0 2020 552 96628 10nF 10% 16V 0402
2BA1 3198 035 14720 4.7nF 5% 25V 0402
2BA2 2020 552 96628 10nF 10% 16V 0402
2BA3 3198 035 14720 4.7nF 5% 25V 0402
2BA5 3198 034 01580 1.5pF 1% 50V 0402
2BA6 3198 034 01580 1.5pF 1% 50V 0402
2BA8 3198 034 01580 1.5pF 1% 50V 0402
2C01 2238 787 15641 22nF 5% 16V 0402
2C02 2238 787 15641 22nF 5% 16V 0402
2C03 2238 787 15641 22nF 5% 16V 0402
2C04 2238 787 15641 22nF 5% 16V 0402
2C06 2238 787 15641 22nF 5% 16V 0402
2C07 2238 787 15641 22nF 5% 16V 0402
2C08 2238 787 15641 22nF 5% 16V 0402
2C09 2238 787 15641 22nF 5% 16V 0402
2C12 2238 787 15641 22nF 5% 16V 0402
2C13 2238 787 15641 22nF 5% 16V 0402
2C15 2238 787 15641 22nF 5% 16V 0402
2C16 2238 787 15641 22nF 5% 16V 0402
2C17 2238 787 15641 22nF 5% 16V 0402
2C18 2238 787 15641 22nF 5% 16V 0402
2C19 2238 787 15641 22nF 5% 16V 0402
2C20 2238 787 15641 22nF 5% 16V 0402
2C22 2238 787 15641 22nF 5% 16V 0402
2C23 2238 787 15641 22nF 5% 16V 0402
2C27 2238 586 59812 100nF 20% 50V 0603
2C28 2238 586 59812 100nF 20% 50V 0603
2C31 2238 586 59812 100nF 20% 50V 0603
2C32 2020 004 90283 10µF 20% 10V 1206
2C33 2238 586 59812 100nF 20% 50V 0603
2C34 2022 552 05679 1µF 10% 16V 0805
2C35 2238 586 59812 100nF 20% 50V 0603
2C36 2022 552 05679 1µF 10% 16V 0805
2C37 2022 552 05679 1µF 10% 16V 0805
2C39 2238 586 59812 100nF 20% 50V 0603
2C40 2238 586 59812 100nF 20% 50V 0603
2C43 4822 124 12108 100µF 20% 4V
2C44 2238 586 59812 100nF 20% 50V 0603
2C45 2020 004 90283 10µF 20% 10V 1206
2C46 2022 552 05679 1µF 10% 16V 0805
2C47 2238 869 15101 100pF 5% 50V 0402
2C48 2238 869 15101 100pF 5% 50V 0402
2C51 2238 586 59812 100nF 20% 50V 0603
2C52 4822 124 23002 10µF 16V
2C53 2020 552 96628 10nF 10% 16V 0402
2C55 2238 586 59812 100nF 20% 50V 0603
2C57 2020 552 96628 10nF 10% 16V 0402
2C58 2020 552 96628 10nF 10% 16V 0402
2C60 2020 552 96628 10nF 10% 16V 0402
2C63 2238 586 59812 100nF 20% 50V 0603
2C65 2020 552 96628 10nF 10% 16V 0402
2C67 2022 552 05679 1µF 10% 16V 0805
2C68 2022 552 05679 1µF 10% 16V 0805
2C70 2020 552 96628 10nF 10% 16V 0402
2C72 2020 552 96628 10nF 10% 16V 0402
2C75 2020 004 00003 330µF 20% 6.3V
2C78 2022 552 05679 1µF 10% 16V 0805
2C79 2022 552 05679 1µF 10% 16V 0805
2C83 2020 552 96628 10nF 10% 16V 0402
2C84 2020 552 00216 220pF 5% 50V 0402
2C85 4822 126 14524 68pF 5% 50V 0402
2C86 3198 034 03380 3.3pF 1% 50V 0402
2G00 2020 552 96628 10nF 10% 16V 0402
2G01 2020 552 96628 10nF 10% 16V 0402
2G02 2020 552 96628 10nF 10% 16V 0402
2G03 2020 552 96628 10nF 10% 16V 0402
2G04 2020 552 96628 10nF 10% 16V 0402
2G05 2020 552 96628 10nF 10% 16V 0402
2G06 2020 552 96628 10nF 10% 16V 0402
2G07 2020 552 96628 10nF 10% 16V 0402
2G08 2020 552 96628 10nF 10% 16V 0402
2G09 2020 552 96628 10nF 10% 16V 0402
2G10 2020 552 96628 10nF 10% 16V 0402
2G11 2020 552 96628 10nF 10% 16V 0402
2G12 2020 552 96628 10nF 10% 16V 0402
2G13 2022 552 05679 1µF 10% 16V 0805
2G14 2020 552 96628 10nF 10% 16V 0402
2G15 2020 552 96628 10nF 10% 16V 0402
2G16 2020 552 96628 10nF 10% 16V 0402
2G17 2020 552 96628 10nF 10% 16V 0402
