Service Modes, Error Codes, and Fault Finding
EN 30 BJ3.0E PA5.
Figure 5-11 “Active” to “Semi Stand-by” flowchart 42 & 50” SDI V5 and 63” SDI V4
G_15960_132.eps
100306
action holder: MIPS
autonomous action
action holder: St-by
Semi Standby
Active
Switch off LVDS signal
(PNX2015)
42" / 50" SDI V5
63" SDI V4
Mute all sound outputs.
Mute all video outputs
Blank PDP display
Switch reset-audio and sound-enable
lines high
Wait 600ms to prevent image
retention
(display error)
Switch the SDI Picture Flag high to prevent
testpattern display in semi-standby mode
To Next Page
