Philips IntelliVue X2 User Manual

2Basic Operation Extending Measurements
16
M3012A Hemodynamic MMS Extension
When attached to an X2 connected to external power (either via the external power supply or a host
monitor), the optional M3012A Hemodynamic extension adds temperature, pressure, and an
additional pressure or a temperature to the monitor. When the X2 is connected to a host monitor, or is
using a PC as a remote display, Cardiac Output (C.O.) measurements can be performed and can be
used to calibrate Continuous Cardiac Output (CCO). These stored C.O. results and the calibrated
CCO measurement are still available in the X2 when it is disconnected from the host monitor.
Te mperatu r e c o nnectors (b r ow n )
Cardiac Output (orange; optional)
Pressure connectors
(red)
MSL Connector to X2

Philips IntelliVue X2 Specifications

General

Brand	Philips
Model	IntelliVue X2
Category	Control Unit
Language	English
