24 Specifications Monitor Performance Specifications
256
Wireless Network
Device Interface
(integrated, for
compatible network
options see below)
Signals
RD+/-, TD+/-: IEEE 802.3 10Base-T, PWR, GND
12.5 V ±20 %, 3.5 W continuous
Frequency Band
USA: 2.400 – 2.483GHz, 5.15 ~ 5.35Ghz, 5.725 ~ 5.825Ghz
Europe: 2.400 – 2.483GHz, 5.15~ 5.35Ghz, 5.47 ~ 5.725Ghz
Japan: 2.400 – 2.483GHz, 4.90 – 5.091GHz, 5.15 – 5.25GHz
China: 2.400 – 2.483GHz, 5.725 ~5.85Ghz
Modulation Technique
802.11b/g
DSSS (DBPSK, DQPSK, CCK)
OFDM (BPSK,QPSK, 16-QAM, 64-QAM)
802.11a
OFDM (BPSK,QPSK, 16-QAM, 64-QAM)
Short Range Radio
Interface
Ty pe Internal SRR interface
Technology
IEEE 802.15.4
Frequency Band
2.4 GHz ISM (2.400 - 2.483 GHz)
Modulation Technique
DSSS (O -QPSK)
Effective radiated
power
max. 0 dBm (1 mW)
M8023A External Power Supply Interface Specifications
Measurement Link
(MSL)
Connectors Male ODU (Proprietary)
Power
48 V output
Power Sync.
RS-422 compliant output 78.125 kHz (typical)
LAN signals
IEEE 802.3 10-Base-T compliant
Serial signals
RS-422 compliant output 78.125 kHz (typical)
Local signals
Not connected
Display Specifications
Integrated QVGA
Display
Sweep Speeds 6.25, 12.5, 25 and 50 mm/s;
Resolution
320 x 240
Refresh frequency
60 Hz
Useful screen
72 x 54 mm (2.8 x 2.1 in)
Pixel size
0.22 x 0.22 mm
X2 (M3002A) Interface Specifications
