5Patient Alarms and INOPs Te c h n i c a l A l a r m M e s s a g e s ( I N O P s )
70
DEVICE REAL DATA
INOP tone
IntelliBridge The monitor is in DEMO mode but the device connected to
the IntelliBridge module reports data that are not flagged as
demo data.
<Device> UNPLUGGED
INOP tone.
IntelliBridge The IntelliBridge module has been unplugged from the rack, or
the whole rack has been disconnected. Silencing this INOP
switches off the measurement.
IntelliBridge INOP abbreviations may differ slightly depending
on the device category.
DEVICE UNSUPPORTED
INOP tone.
IntelliBridge Device identification completed, but no appropriate device
driver installed.
IntelliBridge INOP abbreviations may differ slightly depending
on the device category.
<EC10/EC40> EQUIP MALF
INOP tone.
IntelliBridge Malfunction in the IntelliBridge module. If this message
appears repeatedly, the module must be replaced. Contact your
service personnel.
ECG/ARRH ALARM OFF
!!ECG/AR ALARM OFF
ECG All ECG alarms have been switched off, or the HR alarm
source is not ECG. To resume ECG alarm generation, switch
ECG alarms on or select ECG as the alarm source.
ECG EQUIP MALF
Numeric is displayed with a -?-
INOP tone.
ECG Contact your service personnel.
The ECG hardware is faulty.
ECG EQUIP MALF T
Numeric is displayed with a -?-
INOP tone.
Monitor Contact your service personnel.
The ECG in the Telemetry device is faulty.
(!!/!!!)<ECG LEAD> LEAD
OFF
Numeric is displayed with a -?-
INOP tone.
ECG Not all the required leads for ECG monitoring are connected.
Check the ECG connections and make sure that the electrode
indicated by <ECG lead> [RA, LA, LL, RL, V or C] electrodes
is attached. In EASI mode, all 5 electrodes must be connected.
ECG EL. NOISY <ECG LEAD> ECG The ECG signal from the named ECG electrodes [RA, LA, LL,
RL, V (or C)] is noisy. Check the ECG connections and make
sure that the electrode indicated is attached.
(!!/!!!)ECG LEADS OFF ECG Check that all of the required ECG leads are attached, and that
none of the electrodes have been displaced.
ECG NOISY SIGNAL
INOP tone.
ECG The ECG signal is too noisy. Check that the electrodes are
properly placed and have not dried out. Remove any possible
sources of signal noise (such as power cords) from the area
around the cable and the patient.
The ECG signal may be saturated or overloaded.
EcgOut EQUIP MALF
INOP tone
ECG Check that the ECG out cable is securely connected. Contact
your service personnel.
EEG EQUIP MALF
INOP tone
EEG The EEG hardware is faulty. Contact your service personnel.
EEG IMPEDANCE HIGH or
EEG1 and/or EEG2 IMPED. HIGH
EEG The signal electrode in one or both channels exceeds the user-
selected impedance limit, or the impedance of a single electrode
exceeds the limit. Check the impedance. If the impedance is
too high, reconnect the electrodes according to the EEG
monitoring setup guidelines. If the INOP persists, contact your
service personnel.
EEG<X> LEAD OFF <n>
[X = channel, n = electrode]
EEG Reconnect specified electrode.
INOP Message, Indication Source What to do
