Phoenix LT4 - Page 126

Phoenix LT4 Lane Machine Operation, Maintenance, and Parts Manual
61-900040-000 Rev. Date 01/22
7-7
Frame Assembly – Base Plate and Side Plates
NUMBER
DESCRIPTION
NUMBER
DESCRIPTION
1
294-116-001
BASE PLATE ASSEMBLY
27
294-116-011
STORAGE CASTER, 2-INCH
2
294-116-003
SIDE PLATE ASSEMBLY, RIGHT HAND
28
294-115-614
OPERATING CASTER, 2-INCH
3
294-116-005
SIDE PLATE ASSEMBLY, LEFT HAND
29
951-638-068
WASHER, EXT. TOOTH COUNTERSUNK, #10
4
294-116-008
REAR PLATE ASSEMBLY
30
01-123
SCREW, PHILLIPS FLAT HEAD, 10-32 X 5/8
5
SA-3012
DUSTER END PLATE ROLLER
31
01-355
SCREW, FLAT HEAD, #6 X 1/4
6
294-115-613
CASTER BRACKET, 2-INCH
32
856-149-001
NUT, HEX FLANGE STOVER LOCK, 1/4-20
7
A-2037
POWER CABLE HOOK
33
844-065-002
NUT, STOVER LOCK, 3/8-16
8
A-0794
CASTER SPACER
34
844-049-002
NUT, STOVER LOCK, 1/4-20
9
294-116-013
LIFT HANDLE
35
951-156-002
WASHER, SPLIT LOCK, 5/16
10
711-520-017
GROMMET, 5/8 ID X 7/8OD X 3/16 PANEL
36
809-865-205
SCREW, HEX 3/8-16 X 1-1/4
11
02-539
CABLE MOUNTING BLOCK, 3/4 X 3/4
37
808-549-120
SCREW, BUTTON HEAD, 1/4-20 X 3/4
12
294-116-019
GUIDE ROLLER AXLE
38
01-056
WASHER, FLAT, 1/4
13
SA-0244
GUIDE WHEEL ASSEMBLY
39
801-749-121
SCREW, FLANGE HEAD FLEX 1/4-20 X 3/4
14
01-161
PHENOLIC WASHER
40
801-749-281
SCREW, FLANGE HEAD FLEX 1/4-20 X 1-3/4
15
A-0024
GUIDE ROLLER SPRING
41
801-765-121
SCREW, FLANGE HEAD FLEX 3/8-16 X 3/4
16
A-0025
GUIDE ROLLER WASHER
42
01-001
SCREW, PAN-HEAD PHILLIPS 6-32 X 0.38, ZINC
17
04-078
GROMMET, 5/16 X 3/4 X 1/8, RUBBER
43
01-416
NUT, 6-32X NYLON LOCKING
18
294-116-014
OIL TANK SUPPORT TUBE
44
808-557-082
SCREW, BUTTON HEAD, 5/16-18 X 1/2
19
294-116-015
FRAME BRACKET
45
830-057-002
NUT, ACORN, 5/16-18
20
294-116-016
OIL TANK TUBE BLOCK, BOTTOM
46
294-115-245
HAND ENTANGLEMENT-CHAIN DECAL
21
294-116-017
OIL TANK TUBE BLOCK, TOP
47
294-115-246
HAND ENTANGLEMENT DECAL
22
294-116-098
OIL TANK SPACER
48
294-115-256
GND STICKER IEC 60417-1-5017
23
294-115-706
OIL TANK RETAINING BRACKET
49
A-1058
PE GROUND DECAL
24
04-118
PIN QR 0.25 X 0.80 NS
50
294-115-237
HAND CRUSH DECAL
25
04-335
CABLE ASSEMBLY, 8”
51
294-115-723
KEEP LEVEL STICKER
26
294-116-018
FOAM OIL TANK DRIP PAD
