Operation
61-900040-000 Rev. Date: 01/22 3-5
Displayed in the columns below the cleaning, oiling, and buffing icon is the information for
each pass. As shown in Figure 3- 6, the first pass and second pass information is displayed
in the two columns below the icons.
The cleaning option is only available on the first pass, cleaning on the second pass would
be counter-productive as it would remove the oil which was applied on the first pass. The
units displayed under the oiling and buffing icons represent the distances, in feet, from the
foul line that this program would oil and buff respectively.
Example
The program shown in Figure 3- 6 would clean the entire lane while applying oil to
the first 18 feet of the lane then buffing to 40 feet on the first pass. On the second
pass it would apply oil to 9 feet and buff it out to 20 feet.
3.2.2 Editing Program Specifications
Editing the Pattern Specifications
The Phoenix LT4 comes with four preprogrammed patterns that will produce a good
bowling condition in most bowling centers. The distances of these patterns can be changed
to best suit each bowling center. Table 3- 2 shows a close-up of the first and second pass
edit buttons which are found on the right side of the screen.
Table 3- 2
