Standard Foams (in the machine)
 Super-High Output (#4), 10 in. (25.4 cm) L x 3½ in. (8.9 cm) H
 Medium-Low Output (#10), 7.8 in. (19.9 cm) L x 3½ in. (8.9 cm) H
 Medium-High Output (#6), 3 in. (7.6 cm) L x 3½ in. (8.9 cm) H
Not available in precut
lengths
Alternate Foams, 3½ in. (8.9 cm) H x 48 in. (121.9 cm) L (Field cut
to size)
 Super-High Output (#4)
 High Output (#5)
 Medium-High Output (#6)
 Medium Output (#8)
 Medium-Low Output (#10)
 Low Output (#11)
 Extra-Low Output (#12)
 Super-Low Output (#13)
 Foam Kit - Contains one 48 in. (121.9 cm) long piece of each
of the wicking foams
 294-115-490
 294-115-488
 294-115-486
 294-115-484
 294-115-482
 294-115-652
 294-115-653
 294-115-654
 294-115-655
2.4 PHOENIX LT4 COMPONENTS OVERVIEW
The following pages contain an overview of the Phoenix LT4 components. The hood has
been hidden in these views which are meant to help familiarize the user with the Phoenix
LT4. For detailed information about the components and their functions, refer to the
Operation, Maintenance, and Parts sections of this manual.
