Troubleshooting
5-2 Rev. Date: 01/22 61-900040-000
5.1.1 General Operation
The machine doesn’t turn
on/the touch screen doesn’t
light up.
Touch screen lights up to
main menu, but machine
won’t start.
Ensure that there is power to the outlet (the breaker isn’t
open or tripped) and that it is of the correct voltage for the
machine.
Ensure that the power cord is firmly plugged into the outlet
and into the power inlet on the machine.
Ensure the POWER switch is ON.
Ensure the oil tank cover is closed. Check that cover is tight
and secure.
Trace the start switch cable out of the left side of the handle
base and back to the control box. If the cable is intact,
replace the start switch.
The encoder error is
displayed
For a screen shot of the
Encoder error refer to
Section 3.2.6 – Error
Messages
When the encoder does not detect the machine is moving,
the encoder error is displayed. Causes of the encoder error
include:
Obstruction on the lane
Restriction of the power cord
Faulty encoder or connection
o Ensure cord is securely plugged in to encoder.
o Ensure cord is not damaged.
Drive motor failure or blown fuse
Misalignment of the machine on the lane
The machine does not stop
at the end of the lane (runs
into the pit) or the End of
Lane error is displayed
For a screen shot of the
End of Lane error refer to
Section 3.2.6 – Error
Messages
Ensure that the optical sensor is not dirty or blocked and that
the sensor cable is firmly plugged into the control box.
Check the EOL delay setting and the brake setting. Refer to
“Settings” in Section 3.2.5 – The Test Area.
Sensor is not adjusted correctly. Refer to Section 4.3.7 –
Adjusting the Optical Sensor.
The E-STOP error is
displayed
For a screen shot of the E-
Stop error refer to Section
3.2.6 – Error Messages
If the E-STOP error is displayed, the E-STOP button and the
cover’s interlock button must both be checked to clear error.
If the yellow collar around the E-Stop button is not visible,
then the button is depressed. The button must be pulled out
and the machine must be turned off and on to clear error.
If the machine cover was opened or removed, close or
reinstall the machine cover and verify the oil compartment
cover is tightly latched. Then turn the machine off and on.
